CO2 Laser Marking Machine for Leather
Chengdu Kelier Electronic Co., Ltd. is one of the leading manufacturers and suppliers of co2 laser marking machine for leather in China. Welcome to buy high quality co2 laser marking machine for leather at competitive price from our factory. Also, customized service is available.
| Brand: KELIER | Model: FC20/30/50F | Origin: Mainland China |
| Provinces: Sichuan | City: Chengdu | Power: 20W/30W/50W |
| DCarving speed：9000mm/s | Voltage: 110V-240V | Weight: Packing Weigth:120kg |
All products, provide 3 years of quality assurance service, any doubt, through after-sales service to provide solutions | ||
Co2 laser markers adopt world famous digital laser scanning head, this Co2 laser markers are quite suitable for users requiring highest precision and fastest speed batch production, tags, nameplate, logos.
Co2 laser markers are widely used in the field of non-metal field, such as: garment & shoes engraving, fabric cutting, medical packaging, handicrafts & gift, food printing, soft drink printing, cigarette code, beverage packaging tobacco printing, rubber marking machine, acrylic marker, water bottle marker, marking on plastic, leather engraving industries.
FEATURES OF CO2 LASER MARKING MACHINE
1.High quality Metal Tube
Co2 laser markers take high quality metal laser tube as the laser source. By 2D fast-speed scanning mirrors swinging as the scheduled angles under the controlling of the computer, the laser focus on the surface of the work piece by focus lens to form images and realize marking and graph processing.
2.Free of maintenance
Metal tube has exquisite beam quality, stable power output, high marking precision, long working life time, and can work for 20,000-30,000 hours free of maintenance, then can be recharged by re-filling with co2 gas, suitable for users requiring batch production and high marking precision.
3.Simple structure
Simple structure, abrasion and rusty against component, the system have the most stable performance and moving precision.
4.Double red positioning
Two red light help you easily align the correct focal length，Only need to adjust the height of the table until the two red light coincidence.
5.Digital scanning laser head
Digital fast-speed scanning laser head, it can be the graph in shortest time to finish fine marking process.
| KELIER Industrial Laser Marker parameters | |
| Optional Model | FG20F/FG30F/FG50F |
| Laser power | 20W30W50W(optional) |
| Laser source | China Max or Raycus German IPG fiber laser |
| Laser wavelength | 1064 nm |
| Beam quality | M2 ＜ 1.4 |
| Modulation frequency | 20kHz~110kHz |
| Marking range | 30mm x 30mm - 300mm x 300mm can be optional |
| Carving speed | 0-12000 mm/s(Adjustable) |
| Carving depth | 0.01~0.4mm(10W) ; ≤1.0mm(50W) according to material |
| Focusing mode | Support for automation or manual |
| Marking speed | 1500-2000characters/Min |
| Minimum line width | 0.002 mm |
| Minimum characters | 0.15 mm |
| Repeatability accuracy | ±0.002 mm |
| Cooling method | Air Cooling |
| Use environment | IP4 Clean, dustless or less dusty |
| Laser type | Pulse or continuous |
| control software | Authorization EZCAD marking control software |
| Graphic format supported | bmp, jpg, gif, tga, png,tif,ai,dxf,dst,plt,etc. |
| Laser indicator | Double Red dot pointer |
| Operating system | Win98/Win2000/WinXP/win7 （64、32bit）win8/win10 |
| working temperature | 0-35 ℃,90% or humidity |
| Power consumption | ≤ 550 W |
| Electricity demand | AC110V-240V±10%，50 HZ/60HZ |
| This product contains computers. The following is the configuration list of the dedicated computers. | |
| Computer configuration parameters | |
| CPU | Intel G630X2/I3 540 |
| Memory | ADATA 4G/8G DDR3L 1600 |
| BIOS | AMI EFI BIOS |
| Super I/O | Winbond W83627DHG-P / HG41/HG55 |
| Ethernet | 1x LAN Intel I211(IO） |
| GPU | Intel HD Graphics |
| Display interface | 1x HDMI:1920×1200@60Hz |
| Hard disk | 60G/120G/500G |
| USB interface | 4xUSB |
| serial port | 1x RS232,COM1,RS422、RS485 |
| operating system | Windows 7 32bit；Can support/Windows 8/Windows 10/Linux |
| working temperature | 0℃～ 60℃ |
| Storage temperature | -40℃～ 85℃ |
| humidity | 5% ～ 95% Relative humidity, no condensation |
Widely used application It can be widely used in leather ,food ,beverage,cloth,electronic,meter,communication instruments,package,etc.can be cooperate with production for online marking.It can proceed marking/carving/engraving/nicking a variety of text, symbols, graphics, images, barcodes, serial numbers,etc.
MACHINE APPLICATION SCOPE AND MATERIIALS
Applicable materials:Can be used in wood,paper,leather,cloth,plexiglass epoxy,acrylic,unsaturated polyester resinand other non-metal materials. Applicable industry:it can be widely used in leather ,food ,beverage,cloth,electronic,meter,communication instruments,package,etc.can be cooperate with production for online marking. It can proceed marking/carving/engraving/nicking a variety of text, symbols, graphics, images, barcodes, serial numbers,etc.
Net weight: 95kg
Total Weight of Wooden Box Packaging:Size 900*800*1060mm, weight:120 kg
Inside: Shockproof multilayer foam packaging high-end, safe, easy to carry and store; support customized packing.
The outer cardboard packaging, the middle use of shockproof foam protection,waterproof, moisture-proof, shockproof.
| Packing list | ||
| It is composed of fiber laser, high-speed scanning mirror, control software, computer, switching power supply control chip set and precision Z-axis elevator. | ||
| Packaging size/weight(mm):850(L)*680(W)*400(D) / 60KG | ||
| Part name | Brand origin | Quantity |
| Fiber laser | Raycus/Max/Ipg | 1 sets |
| High speed scanning galvanometer | Beijing Jin Haichuang | 1 sets |
| Focusing lens | Singapore wavelength | 1 sets |
| Marking software | EZCAD | 1 sets |
| Indicator locator | Xi'an sapling | 1 sets |
| Power switch | Taiwan Meanwell | 1 sets |
| Laser frame | Self-control | 1 sets |
| Print foot | Customized | 1 sets |
| Equipment switch | Shanghai Jia Jia | 1 sets |
| Control computer(Order required ) | desktop computer | 1 sets |
| Instructions | Video, text and pictures | 1 sets |
Q1: How can I get the best machine for me?
You can tell us your working material, detail work by picture or vedio so that we can judge whether our machine can meet your need or not. Then we can give you the best model depends on our experience.
Q2: This is the first time I use this kind of machine, is it easy to operate?
We will send you manual and guide vedio in English, it can teach you how to operate the machine. If you still can not learn how to use it, we can help you by "Teamviewer" online help software.Or we can talk by phone, email or other contact ways.
Q3: This model is not suitable for me, do you have more models available?
Yes, we can supply many models . (110*110mm-300*300mm working size ) , and laser wattage (ranging from 30 watts to 100 watts) If you'd like help determining which laser is right for your application or receive pricing information.
Q4:What's the guarantee, in case the machine breaks down?
The machine has one year guarantee. If it breaks down, generally speaking, our technician will figure out what the problem may be, according to client s feedback. Parts except for consumable parts will be replaced for free if the problems are caused by quality fault.
Q5:How about the documents after shipment? And how long is the delivery time?
After shipment, we'll send all original documents to you by email or by DHL, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.
For standard machines, it would be 5-10days; For non-standard machines and customized machines according to client s specific requirements, it would be 15 to 30 days.
Q6:How's the payment?
Telegraphic Transfer(T/T) to our official company bank account or Western Union(WU) or via alibaba trade insurance order payment
Q7:Do You Arrange Shipment For The Machines?
Yes, For EXW price, It is costly to pick up machine from our factory ,we could send machines to any Chinese sea port warehouse by add some domestic shipping cost.
For FOB or CIF price, we will arrange shipment for you.
Q8:If the machine has problem in my place, how could I do?
We could send free parts to you in warranty period if machines have any problem under "normal use".
